TENKILOMETERS altus qualitas EN8145X6 BAND DUAL WIFI6 XG-PON ONU ONT FTTH unitas ultra-patens accessum, altum effectum, et late coverage pro clientibus offert. Cum alta transmissione EN8145X6 experientiam praebet summus qualitas tam vocis quam muneris notitia — plus futuri muneris subsidii facultates — OptiXstar EN8145X6 adiuvat conatibus explicandas solutiones omnium accessuum competitive omnium opticorum.
|
Exemplar |
EN8145X6 |
|
Port |
4 x GE, 1 x POTS, 1 x USB, 2.4G/5G Wi-Fi 6 |
|
Type |
XG-PON |
|
Dimensiones (H x W x D) |
40 x 185 x 120 mm (sine antenna et pads externa) |
|
Pondus (sine nibh potentia) |
Proxime CD g * |
|
Temperature operating |
0-40°C |
|
operating Umor |
5-95% RH (non-condensatione) |
|
Virtus nibh Input |
100-240 V AC, 50/60 Hz |
|
Ratio Power Supple |
11-14 V DC, 1.5 A |
|
Maximum Power Consummatio |
18 W |
|
Antenna |
Antennae externae |
|
Modus institutionem |
Desktop |
|
Virtus salutaris |
COC V7 |
|
USB Portus |
USB 2.0 |
|
FTP-fundatur network repono |
|
|
File / Print sharing secundum SAMBA |
|
|
DLNA munus |
SC/UPC
DTMF
WPA3
QinQ VLAN
Classis N1/N2a/E1
Receptoris sensus: -28 dBm
flumine et amni FEC
SR-DBA et NSR-DBA
MAC oratio cognita
Auto celeritatum portus (10/100/1000 Mbit/s)
Maximum CURSUS: 4
T.30/T.38/G.711 fax modus
Subitis vocat (cum HAUSTUS protocol)
IEEE 802.11 b/g/n/ax (2.4G)
IEEE 802.11 a/n/ac/ax (5G)
2 x 2 MIMO (2.4G)
2 x 2 MIMO (5G)
Antennae compendium: 5 dBi
WMM / Multiplex SSIDs / WPS
2.4G et 5G concurrency
Beamforming
Cohors gubernaculo
DL OFDMA
DL MU-MIMO
1024 QAM
160 MHz frequentia Sed
Necem Clausus Filter (WBF)
Wavelengths: US 1260-1280 um, DS 1575-1580 nm
Flexibile mapping inter portum GEM et TCONT
Air interface rate: 574 Mbit/s (2.4G), 2.402 Gbit/s (5G)
2.5 Gbit/s flumine, 10 Gbit/s amni
G.711A/μ, G.729a/b et G.722 descriptam/decoding
Aer portum-fundatur VLAN tags et tag remotionem
1:1 VLAN, N:1 VLAN vel VLAN transmissio perspicua
Mac oratio limite numerum doctorum
SN/Password/SN + Password/Bi-directional authenticas secundum OMCI
